PV module temperature sensorPVMT01
BEST Good
제품사양
| PVMT01 | |
|---|---|
| Sensor type | Pt1000 Class A Platinum resistance thermometer (PRT) |
| Sensor connection | 4-wire |
| Sensor housing | aluminium disk |
| Sensor and cable | -40 °C to +150 °C |
| Connector | -40 °C to +80 °C |
| Measurement accuracy | ± (0.15 + 0.002∙T) °C |
| Compliance | IEC 61724-1:2021, Class A |
| Number of sensors required | 3 per monitoring station required, minimum 6 per PV system, depending on the size of the system as per IEC 61724-1 |
| IP protection class | IP67 |
| Disk material | anodized aluminium |
| Disk diameter | 25 x 10⁻³ m |
| Disk thickness | 5.5 x 10⁻³ m |
| Insulation resistance | > 2 GΩ at 1 kV as per IEC 60060-1 |
| Adhesive material | acrylic sticker |
| Adhesive thickness | 0.13 × 10⁻³ m |
| Total heat transfer coefficient | > 500 W/(m2∙K) as required in IEC 61724-1 |
| Cable length | 1 m |
| Cable extension | to preferred length, should be extended by the user |
| Cable diameter | 2.5 × 10⁻³ m |
| Connector type | 4P, male M12-A connector |
| Cable connector | 4P or 5P female M12-A connector |
